Parameters

• Display

  7"@ TFT Color Touch LED Screen (600*1024)

• Camera

  WDR Binocular Camera @ 1MP

• Operation System

  Linux

• Hardware

  CPU: Dual Core@1GHz
  RAM: 512MB; ROM: 8GB
  Speaker: 8 ohm@1 W
  Microphone: *1 (Sensitivity: -32dB / Omni-directional / Signal-to-Noise Ratio: -32dB /
  Impedance: 2.2kΩ)
  Supplement Light: No

• Authentication Method

  Face / Card / Password (Virtual Keypad)

• Face Template

  50,000 (1:N)

• Card Capacity

  50,000 (1:N) (Standard)

• User Capacity

  50,000 (1:N) (Standard)

• Transaction Capacity

  300,000

• Password Capacity

  8 Digits

• Biometric Authentication Speed

  less than 0.35 sec (Facial Authentication)

• Touchless Biometric Authentication Distance

  30cm to 200cm (Facial Authentication)

• False Acceptance Rate (FAR) %

  FAR ≤ 0.01% (Visible Light Facial
  Authentication)

• False Rejection Rate (FRR) %

  FRR ≤ 0.02% (Visible Light Facial
  Authentication)

• Card Type

  ID Card @ 125 kHz (Standard)
  IC Card @ 13.56 MHz (Optional)

• Communication

  TCP/IP*1, Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional), Wiegand (Input or Output)*1
  RS485: ZKTeco RS485*1, USB: Type A (USB Drive Only)*1
  Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, 12V Output*1

• Standard Functions

  ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups,
  Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status
  Switch (Effective only under T&A rules), Multiple Authentication Methods, SIP Client (Version
  2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC
  Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)

• Optional Functions

  IC Card, Wi-Fi, Wireless Doorbell

• Video Intercom

  Video Intercom(ZKTeco Private Protocol via TCP/lP)
  Support Devices:
  Indoor Monitor: VT07-B01, VT07-B01-W
  Video Intercom (Standard SIP Protocol)
  Support Devices:
  Indoor Monitor: VT07-B22L, VT07-B26L-W
  Software: ZKBio CVSecurity
  Mobile App: ZKBio Zlink, ZKBio Zexus


• Power Supply

  DC 12V 3A (Optional)

• Access Control Interface

  RS485 (RS485 Card Reader / Biometric Reade

• Dimensions(L*W*D)

  214mm * 115mm * 22.3mm (L*W*H)

• Ingress Protection Rating

  IP65 (waterproof and dustproof )

• Supported Software

  On-Premise Software: ZKBio CVSecurity (AC PUSH) & ZKBio Time (TA PUSH)
  Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App)

• Working Humidity

  10% to 90% RH (Non-condensing)

• Certifications

  ISO14001, ISO9001, CE, FCC, RoHS
