Parameters

• Display

  4.3"@ TFT Color Touch LED Screen (272*480)

• Camera

  WDR Binocular Camera @ 1MP

• Operation System

  Linux

• Hardware

  CPU: Dual Core@1GHz
  RAM: 512MB; ROM: 8GB
  Speaker: 8ohm @1W
  Microphone: *1 (Sensitivity: -42 dB/ Omni-directional/ Signal-to-Noise Ratio: 58 dB/
  Impedance: 2.2kΩ)
  Supplement Light: No

• Authentication Method

  Face / Card / Password (Virtual Keypad)

• Face Template

  1,500 (1:N) (Standard)

• Card Capacity

  1,500 (1:N) (Standard)

• User Capacity

  1,500 (1:N) (Standard)

• Password Capacity

  8 Digits

• Transaction Capacity

  200,000 (1:N)

• Biometric Authentication Speed

  Less than 0.35 sec (Facial Authentication)

• Touchless Biometric Authentication Distance

  30cm to 200cm (Facial Authentication)

• False Acceptance Rate (FAR) %

  FAR ≤ 0.01% ( Visible Light Facial Authentication)

• False Rejection Rate (FRR) %

  FRR ≤ 0.02% ( Visible Light Facial Authentication)

• Biometrics Algorithm

  ZKFace V4.0

• Card Type

  ID Card@125 kHz (Standard)
  IC Card@13.56 MHz (Optional)

• Communication

  TCP/IP*1, Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz, Wiegand (Input or Output)*1, RS485:
  ZKTeco RS485*1, USB: Type A (USB Drive Only)*1,
  Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, 12V Output*1

• Standard Functions

  Backup Battery, ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User
  ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch
  Alarm, Automatic Status Switch, Multiple Authentication Methods, SIP Client (Version 2.0),
  ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A) AC Push
  and TA Push Protocol Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)

• Optional Functions

  IC Card, Wireless Doorbell

• Access Control Interface

  RS485 ( RS485 Card Reader / Biometric Reader)

• Video Intercom

  Video Intercom (ZKTeco Private Protocol via T CP/lP)
  Support Devices:
  Indoor Monitor: VT07-B01, VT07-B01-W
  Video Intercom Video Intercom (Standard SIP Protocol)
  Support Devices:
  Indoor Monitor: VT07-B22L, VT07-B26L-W
  Software: ZKBio CVSecurity
  Mobile App: ZKBio Zlink, ZKBio Zexus

• Power Supply

  DC 12V 3A,
  Backup Battery (2000 mAh, Lithium Battery)

• Dimension

  175.00 mm * 84.50 mm * 21.65 mm (L*W*H)

• Ingress Protection Rating

  IP65 (waterproof and dustproof)

• Net Weight

  0.264 Kg

• Operating Humidity

  10% to 90% RH (Non-condensing)

• Operating Temperature

  -5°C to 45°C

• Supported Software

  On-Premise Software: ZKBio CVSecurity (AC PUSH) & easy TimePro (TA PUSH)
  Cloud-based Software: BioTime Cloud 2.0, ZKBio Zlink (Supports Web Portal & Mobile App)

• Certifications

  ISO14001, ISO9001, CE, FCC, RoHS
